全球经销商埃及、埃塞俄比亚、肯尼亚和吉布提

AGBL-埃及

地址

25A Nagib Mahfouz St.,New Nerco Buildings Degla, 开罗-埃及

电话

+2 02 2754-4000

传真

+2 02 2754-6000

电子邮件

dx@agbl.net

网站

www.agbl.net

过滤器：Ethiopia清除所有国家

请从下面的菜单中选择一个国家/地区：

国家/地区阿富汗阿尔及利亚安哥拉亚美尼亚澳大利亚奥地利阿塞拜疆巴林孟加拉国比荷卢经济联盟贝宁博茨瓦纳巴西保加利亚布基纳法索布隆迪喀麦隆加拿大乍得智利中国哥伦比亚刚果克罗地亚塞浦路斯捷克共和国刚果丹麦吉布提埃及赤道几内亚爱沙尼亚埃塞俄比亚芬兰法国加蓬冈比亚德国加纳希腊几内亚几内亚比绍香港匈牙利印度印度尼西亚伊拉克爱尔兰以色列意大利象牙海岸日本约旦哈萨克斯坦肯尼亚韩国科威特吉尔吉斯斯坦拉脱维亚黎巴嫩莱索托利比亚立陶宛马达加斯加马拉维马来语西亚马里马耳他毛里求斯毛里求斯墨西哥摩洛哥莫桑比克纳米比亚尼泊尔新西兰尼日尔尼日利亚挪威阿曼巴基斯坦巴勒斯坦秘鲁菲律宾波兰葡萄牙波多黎各卡塔尔俄罗斯卢旺达沙特阿拉伯塞内加尔塞拉利昂利比里亚新加坡斯洛文尼亚西班牙斯里兰卡斯威士兰瑞典瑞士台湾塔吉克斯坦坦桑尼亚多哥突尼斯土耳其土库曼斯坦阿联酋乌克兰英国美国乌兹别克斯坦也门赞比亚津巴布韦产品

请选择产品：

产品MicroStationOdinOmniLogLinkedInTwitterFacebook

版权所有 2023 Biolog，保留所有权利用户隐私政策Site by Metropolis

产品产品实验室服务应用资源网络研讨会新闻与活动贸易展览新闻发布​​公司关于我们联系方式提交样品全球经销商芬兰和爱沙尼亚

Labema Oy

地址

Elimäenkatu 9 B,00510 HELSINKI

电话

+358 (0)9 274 67 425

电子邮件

labema@ labema.fi

网站

www.labema.fi

过滤器：爱沙尼亚清除所有国家

请从下面的菜单中选择一个国家/地区：

国家/地区阿富汗阿尔及利亚安哥拉亚美尼亚澳大利亚澳大利亚奥地利阿塞拜疆巴林孟加拉国比荷卢经济联盟贝宁博茨瓦纳巴西保加利亚布基纳法索布隆迪喀麦隆加拿大乍得智利中国哥伦比亚刚果克罗atia塞浦路斯捷克共和国D.R.刚果丹麦吉布提埃及赤道几内亚爱沙尼亚埃塞俄比亚芬兰法国加蓬冈比亚德国加纳希腊几内亚几内亚比绍香港匈牙利印度印度尼西亚伊拉克爱尔兰以色列意大利象牙海岸日本约旦哈萨克斯坦肯尼亚韩国科威特吉尔吉斯斯坦拉脱维亚黎巴嫩莱索托利比亚立陶宛马达加斯加马拉维马来语西亚马里马耳他毛里求斯毛里求斯墨西哥摩洛哥莫桑比克纳米比亚尼泊尔新西兰尼日尔尼日利亚挪威阿曼巴基斯坦巴勒斯坦秘鲁菲律宾波兰葡萄牙波多黎各卡塔尔俄罗斯卢旺达沙特阿拉伯塞内加尔塞拉利昂利比里亚新加坡斯洛文尼亚西班牙斯里兰卡斯威士兰瑞典瑞士台湾塔吉克斯坦坦桑尼亚多哥突尼斯土耳其土库曼斯坦阿联酋乌克兰英国美国乌兹别克斯坦也门赞比亚津巴布韦产品

请选择产品：

产品MicroStationOdinOmniLogLinkedInTwitterFacebook

版权所有 2023 Biolog，保留所有权利用户隐私政策Site by Metropolis

产品产品实验室服务应用资源网络研讨会新闻与活动贸易展览新闻发布​​公司关于我们联系方式提交样品Thank you for visiting nature.com. You are using a browser version with limited support for CSS. To obtain the best experience, we recommend you use a more up to date browser (or turn off compatibility mode in Internet Explorer). In the meantime, to ensure continued support, we are displaying the site without styles and JavaScript. Helium Ion Microscopy (HIM) for the imaging of biological samples at sub-nanometer resolution AbstractScanning Electron Microscopy (SEM) has long been the standard in imaging the sub-micrometer surface ultrastructure of both hard and soft materials. In the case of biological samples, it has provided great insights into their physical architecture. However, three of the fundamental challenges in the SEM imaging of soft materials are that of limited imaging resolution at high magnification, charging caused by the insulating properties of most biological samples and the loss of subtle surface features by heavy metal coating. These challenges have recently been overcome with the development of the Helium Ion Microscope (HIM), which boasts advances in charge reduction, minimized sample damage, high surface contrast without the need for metal coating, increased depth of field and 5 angstrom imaging resolution. We demonstrate the advantages of HIM for imaging biological surfaces as well as compare and contrast the effects of sample preparation techniques and their consequences on sub-nanometer ultrastructure. IntroductionThe Scanning Electron Microscope (SEM) has become one of the fundamental tools used in the study of exterior morphology and structure for biological samples1. More recently it has become an essential tool in the study of connectomics and cellular interactions with advances in serial block-face imaging techniques, for example, using either an in situ microtome2 or focused-ion beam (FIB) milling3. The caveat, however, is that conventional SEM imaging requires samples to be conductive and vacuum friendly, both of which can be accomplished via drying of the sample and coating it with a heavy metal1. Although this method of sample preparation has been standard for many years, there are some instances where minute surface details can be obscured by the metal coating or where the sample is too delicate or small to survive the requisite fixation and drying procedures4,5,6. To combat this, numerous advances have been made to reduce charge as well as image samples in their hydrated form.One of the most effective methods used to minimize the charging effects observed in insulating samples is to reduce the accelerating voltage of the electron beam, also known as low-voltage scanning electron microscopy (LVSEM)7. Lowering the voltage in conjunction with brighter field-emission sources and state of the art detectors has the advantage of higher resolution, increased topographical contrast and surface sensitivity as well as increased secondary electron generation. However, as the voltage decreases, chromatic aberration increases and depth of field decreases with the necessary decrease in working distance, thus limiting the low voltage range of most conventional non aberration-corrected SEMs8,9,10. An alternative approach is to delay the dehydration of samples using variable and extended pressure imaging techniques11,12. By injecting nitrogen gas (variable pressure) or water vapor (extended pressure) into the imaging chamber, charge can be negated by creating secondary ionization products of the working gas molecules1. Beam stability is maintained in these systems by means of an In-Lens differential pumping system that allows the maintenance of a high vacuum in the electron gun with a low vacuum in the imaging chamber. Although useful, this technique is limited in resolution and signal to noise as a result of beam skirting13. In addition, there is an increased chance of beam-induced damage to the sample due to the higher accelerating voltages required for imaging within a gaseous environment14.One of the most formidable developments in imaging biological surfaces in their most native form without any chemical fixation is Cryo-SEM15, which freezes or cryo-immobilizes the sample and transfers it to a chilled stage prior to imaging. Although it is possible to maintain gross morphology with this technique, samples can potentially sublimate under high vacuum conditions thus increasing the risk for charging. This often requires the frozen samples to be sputter coated or imaged in a variable pressure environment14,16.Notwithstanding these advances in controlling charge and maintaining biological surface structure, they all still suffer from limitations in both resolution and contrast. Recently, an ultra-high brightness gas field ionization source (GFIS) has been developed for use as an ultra-high resolution and high contrast imaging system (Orion, Carl Zeiss, Peabody, MA)17. Despite this relatively contemporary innovation, the original concept of a Field Ion Microscope (FIM) based on helium ions was originally proposed by Erwin M眉ller in 195618. However, recent refinements to the design overcame previous limitations and now boast a reproducible and stable ion source over many days. The key to the systems performance is its source, which is shaped to a three-sided pyramidal tip consisting of only three atoms at the apex. When the tip is cryogenically cooled and exposed to a high voltage (30鈥卥V) in the presence of helium, an ionized gas field is generated at the apex of the tip. This is due to field only being intense enough at those three atoms to efficiently ionize the helium gas. As such, the ion emission originates preferentially from those atoms at the apex, of which only one is selected for imaging. Thus imaging occurs using a single atom as the ion source. The extracted ions are accelerated down the column of the microscope in the form of a beam that is then shaped and raster scanned much in the same fashion as in an SEM. Due to the ultra high brightness of the GFIS a very small beam defining aperture may be used and therefore spherical and chromatic aberrations of the ion optical column are insignificant. The helium ion microscope therefore exhibits substantially higher resolution with a larger depth of field resulting in an estimated resolution that is five times greater than that of a modern FE-SEM17. Also, since the de Broglie wavelength of a helium ion is very small (below one picometer for a 30鈥卥V accelerating voltage) the spot size of the scanned beam is not limited by diffraction aberration17. In addition to the increase in resolution, the increased mass of a helium ion results in a strong forward scattering of the ions causing the majority of the beam energy to be deposited in deeper areas of sample. This results in high contrast secondary electron emission deriving mostly from the primary beam (SE1 electrons), with typically 2鈥? electrons produced per helium ion19. Because of the deeper penetration of the forward scattered ions in biological samples, there is a much lower propensity for beam-induced surface-damage due to lower sample densities as compared with crystalline materials such as silicon. The lack of deposition of energy at the sample surface results in minimal damage at 30鈥卥V where currents used for imaging range from 0.1鈥?.4鈥卲A19,20,21,22. Furthermore, the sputter rate of helium is two orders of magnitude lower than gallium at comparable beam energies. This results in biological samples being able to be imaged repetitively for a relatively long time before any noticeable beam damage occurs. Such effects may be visible as slight deformations or almost negligible material removal (a polishing effect) from the sample surface. For electrically insulating samples, positive charge resulting from the ion beam is easily compensated by directing a very low voltage electron beam (flood gun) at the sample. The use of such a device does not have any affect on the helium ion spot size and thus has no negative impact on resolution19. Also, the recent development of patterning scan engines (Fibics, Ottawa, Canada) allow the routine nanoscale milling and modification of samples17.To date, helium ion microscopy has been primarily been used in high-contrast imaging of inorganic materials; however23,24, there have been some limited instances where it has been used in imaging of biological samples. These have included imaging nanofibers in hyaluronan-based pericellular matrix25, edge detection of colon cancer cells26, visualization of articular cartilage networks27 and the ultrastructure of Lepidoptera scales28. More recently, HIM has been used successfully to visualize the microvilli and glomerular structures in the rat kidney29 and nanoscale cuticle structures on Drosophila melanogaster30. In addition to using slow helium ions to image, research has been undertaken on the development of a Mega Electron Volt (MeV) microscope for whole cell density mapping31.Despite these isolated demonstrations of HIM imaging, there has yet to be any significant interest demonstrated in developing HIM technology for biological applications. As such, the aim of this study was to undertake a set of experiments to test if the advantages described above would lead to improved insight on biological specimens. Therefore the HIM was tested on a traditionally difficult range of challenging biological samples. In addition, besides demonstrating the resolution and contrast abilities of the method, we also compared results to a modern FE-SEM as well as identify any potential consequences of sample preparation (critical point drying and sputter coating), as seen in the ultrastructure of the various specimens.ResultsTo compare SEM to HIM, a set of biological samples were chosen where the unique aspects of the HIM system could provide advantages in their imaging. (i) Arabidopsis thaliana, the most favored model system for plant biology to study exterior nanoscale morphology (ii) HeLa cells, as an adherent cell type to study membrane surface details and filopodia, (iii) BoFeN1 iron-oxidizing bacteria to showcase the effects of drying and heavy metal coating on surface morphology and (iv) Pristionchus pacificus predator nematodes to illustrate the depth of field of the HIM system and its precision milling abilities.Imaging parameters were chosen to provide a rational comparison between the two technologies. Since the overarching goal of the study was to investigate uncoated samples as well as to achieve high-resolution images at high magnifications, the FE-SEM was operated at a low voltage (0.7鈥?.0鈥卥V for uncoated samples and 3鈥卥V for coated samples) with an aperture size of 30鈥呂糾. Both In-Lens (I-L) and Everhart-Thornley (E-T) detectors were used to image the samples as only secondary electrons were studied in the HIM. Alternatively, the HIM was operated at an optimal imaging voltage of 30鈥卥V, an aperture size of 5鈥呂糾 and a beam blanker current of 0.5鈥卲A. An Everhart-Thornley (E-T) detector was used to image the samples. In both instances, working distance and tilt were slightly varied between images and samples to produce optimal imaging conditions of electron detection, depth of field and charge compensation.Care was taken during sample preparation to ensure that any artifacts were minimal. To reduce drying artifacts and to make the samples vacuum stable, proper fixation and critical point drying (CPD) was necessary. It was found that small plants and nematodes could be fixed with ice-cold ethanol and then directly critical point dried. Cells, however, were more sensitive to the CPD process and required the use of robust fixatives such as glutaraldehyde to maintain intact membrane structures. In addition all samples were kept in a desiccator or under vacuum at all times to minimize artifacts caused by rehydration of the tissues from native humidity.Arabidopsis thalianaAs a model plant, Arabidopsis was chosen as a stable and well-studied organism to compare the effects of imaging at ever increasing magnification ranges between the FE-SEM and HIM. Since the samples were critical point dried and uncoated, they were prone to charging and thus low voltage ( 1鈥卥V) imaging in the FE-SEM was required. When compared to the HIM, images in the SEM were similar at lower magnifications in both contrast, depth of field and lack of charging (Figure 1a and b panels). However, despite low-voltage imaging in the FE-SEM, the sample exhibited charging effects starting at ~20鈥卥X magnification (3.4鈥呂糾 field of view), resulting in motion shown by streaks or bands within the image (Figure 1c, white arrowheads). In addition, at ~38鈥卥X (2.1鈥呂糾 field of view) fine textures on the sample surface and minute ridges on the cuticle could no longer be discerned. By 163鈥卥X (478鈥卬m field of view), the cuticle could no longer be clearly resolved in the FE-SEM as a result of either heavy charging or beam-induced thermal drift due to the very small probe size necessary to achieve such a magnification (Figure 1c far right panel). In contrast, charging in the HIM was completely eradicated via the use of the microscope\'s charge-compensation flood gun. As a result, higher magnifications up to 163鈥卥X could be easily achieved without any form of charging, thermal drift and most importantly beam-induced damage, thus revealing fine surface structures, such as the defects in the wax on a single ridge of the plant\'s cuticle (Figure 1d panels).Figure 1Comparison of HIM and FE-SEM imaging in Arabidopsis thaliana.(a) Low and (c) high magnification series of uncoated and critical point dried Arabidopsis thaliana sepal cuticle structures in the FE-SEM at low voltage ( 1鈥卥V) using an Everhart-Thornley (E-T) detector. At 22鈥卥X magnification, charging artifacts become visible in the form of streaks or bands (white arrowheads) that go horizontally across the image. (b) Low and (d) high magnification series of the sepal cuticle structure in the HIM. Throughout the magnification range, no charging or imaging artifacts are apparent and cuticle structures are still visible at 163鈥卥X. Scale Bars: (a,b) 10鈥呂糾 (c,d) 200鈥卬m.Full size imageHeLa cellsAs a model cell line used in many cell biology applications, HeLa cells were chosen to demonstrate the effects of imaging fine structures such as filopodia and cell adhesion points in both HIM and SEM. The comparison of two cells in mitosis at low magnification (Figure 2a) clearly shows the efficient charge neutralization ability of the HIM over the FE-SEM. The intensity-saturated regions of the cell as well as the appearance of dark bands on the glass coverslip indicated the areas of charging in the FE-SEM. As the magnification was increased to 38鈥卥X (3鈥呂糾 field of view), two separate effects can be seen within each microscope. In the HIM, filopodia had a tendency to appear 鈥済hosted鈥?or somewhat translucent when there were additional features in close z-proximity (Figure 2b, right panel, black arrowheads). As described previously, this is likely due to the deeper penetration of the helium ions that pass through thinner regions of the sample, generating not only SE1 electrons on the surface closest to the source, but also secondary electrons on the surfaces immediately behind them31. This is due to the ion beam not changing geometry over that distance. In the SEM, the filopodia exhibited edge effects, a common artifact of low-voltage imaging of fine or filamentous structures (Figure 2b, left panel, black arrowheads). As magnification was increased a third time to 163鈥卥X (700鈥卬m field of view) (Figure 2c), the filopodia were easily recognizable in both microscopes, however, the surface features and textures were indistinguishable in the FE-SEM (Figure 2c, left panel).Figure 2Comparison of HIM and FE-SEM imaging of mitotic HeLa cells.(a) Low magnification of uncoated critical point dried HeLa cells grown on glass coverslips in metaphase in both the FE-SEM at low voltage ( 1鈥卥V) with an In-Lens (I-L) detector (left panel) and HIM (right panel). Whilst the HIM exhibits high contrast and depth of field, the FE-SEM shows signs of charging in the form of saturated areas and dark and light banding on the glass coverslip. (b) At ~38鈥卥X (3鈥呂糾 field of view), the 鈥済hosting鈥?effect of some filopodia becomes apparent in the HIM (right panel, black arrowheads), while the FE-SEM exhibits a large amount of edge effects (left panel, black arrowheads). (c) High magnification of the same dividing cells shows no sign of loss of resolution in the HIM compared to the FE-SEM as depicted by the presence of cell membrane textures. Scale Bars: (a) 5鈥呂糾 (b) 500鈥卬m (c) 100鈥卬m.Full size imageIn addition to the comparison of the HIM to the SEM, the maximum overall resolution of the HIM was demonstrated in Figure 3. A random HeLa cell was chosen (Figure 3a) and from there, a single filopodia attachment point was recorded at increasing magnifications (Figure 3b鈥揹) until a maximum magnification of 285鈥卥X, or a field of view of 400鈥卬m was achieved. At this magnification, the sample contrast between the cell and the glass coverslip was still high enough to discern the size of the attachment point (~5鈥卬m). Remarkably, repeated imaging of these small and highly delicate structures caused no discernable beam damage.Figure 3Single filopodia attachment point of a HeLa cell as illustrated using the HIM.(a) A single cell was chosen that had minimal contact with neighboring cells and visible attachment points to the glass substrate. (b,c) The magnification was increased on a single adhesion point to a final magnification of (d) ~285鈥卥X (400鈥卬m field of view) while maintaining high enough contrast to depict an attachment width of ~5鈥卬m. Scale Bars: (a) 5鈥呂糾 (b) 1鈥呂糾 (c,d) 50鈥卬m.Full size imageIron-oxidizing bacteria (BoFeN1)The nitrate-reducing Acidovorax sp. strain BoFeN1, originally isolated from anoxic freshwater sediments of Lake Constance causes oxidation of Fe(II) either by an enzymatic process or by an abiotic reaction of Fe(II) with nitrite, which is an intermediate denitrification product32. It is known from numerous previous studies that, when grown in the presence of Fe(II), some cells tend to grow a crust of platelet-shaped Fe(III) minerals on the cell surface while others do not33.The HIM images that were acquired at low magnification show three-dimensional cell mineral aggregates (Figure 4c and d, left panels). The images show a large depth of field in comparison to FE-SEM images that were acquired at low voltage at similar magnifications (Figure 4a and b, left panels). Low voltages were necessary in particular for imaging the uncoated samples by FE-SEM to avoid charging artifacts. The comparison of coated and uncoated samples by HIM at high resolution reveals two major artifacts caused by the sputter coating with platinum. Comparing the coated and non-coated critical point dried samples (Figure 4c and d) it appears that the crystallites attached to the cells end in rather sharp tips without coating, whereas mineral platelets on the cell surfaces of the platinum-coated samples appear to be relatively thick at the end and sometimes even show globule-like structures in the size-range of tens of nanometers (Figure 4c, right panel). A potential explanation for this change in mineral shape and structure might be a localized, preferential deposition of platinum due to charge-effects on the electrically isolating mineral structures. Additionally, the critical point dried samples show especially clean surfaces, whereas the surfaces of the minerals in plunge-frozen and freeze-dried samples appear to have a much smoother envelope in the case of the uncoated samples. We attribute this to a thin layer of extracellular polymeric substances (EPS) coating the whole aggregate. In contrast, we observed a relatively rough surface in the case of the platinum-coated samples (see Supplementary Fig. 1). This indicates that sputter coating with platinum introduces an artificial surface roughness.Figure 4Comparison of platinum coated and uncoated sample preparations critical point dried BoFeN1 bacteria in both the HIM and FE-SEM at low and high magnifications.(a) Low and high magnifications of platinum coated (using an Everhart-Thornley (E-T) detector) and (b) uncoated bacterium (using an In-Lens (I-L) detector) in the FE-SEM reveal Fe(III) platelet structures that were on the order of tens of nanometers in size. Although the structures appeared much more flat in the uncoated sample, resolution was limited due to the necessity to use low-voltage imaging. (c) Low and high magnifications of platinum coated and (d) uncoated bacterium in the HIM reveal the coating induced artifact of globular structures and artificial textures on the platelets. The uncoated platelets in the HIM were for the first time revealed to be relatively flat with relatively sharp-tipped cellular attachments. Scale bars: 250鈥卬m.Full size imageHIM imaging has, for the first time, allowed the identification of this coating artifact because of the higher spatial resolution in combination with the capability of analyzing non-conductive, uncoated samples. In addition, the existence of an EPS-envelope coating the minerals in plunge-frozen and freeze-dried samples could only be unambiguously shown in non-coated samples. Furthermore, sputter coating with platinum seemed only to affect the surface of the chemically fixed and critical point dried bacteria by creating a textured surface with network-like structures that created high secondary electron-signals (Figure 4c). We did not observe this effect when the cells were not coated with platinum (Figure 4d). We also did not observe these structures on plunge-frozen and freeze-dried samples, both with and without the heavy metal coating (see Supplementary Fig. 1). Since dehydration in solvents such as ethanol (a necessary step preceding critical point drying), can cause shrinkage in biological samples34, it is also possible that a similar effect could lead to a slightly textured cell surface that is potentially electrically insulating and thus, could favor localized deposition of platinum due to charge induced effects.Predator nematode - pristionchus pacificusFinally the predator nematode, Pristionchus pacificus35 served as an ultrastructural imaging challenge in the sense that the interior of the mouth cavity, including teeth morphology, had never been successfully imaged. A sister nematode, Parasitodiplogaster laevigata, a parasite of fig wasps has previously been shown via SEM imaging to have a protruding tooth structure and a visible Dorsal Esophogeal Gland Orifice (DEGO) located at the base of the protruding tooth36. However, in the initial HIM imaging of Pristionchus pacificus, it was revealed that a membranous sheath obscured the primary tooth structure (Figure 5a). This afforded an opportunity to employ another unique aspect of the HIM system 鈥?precision nano-machining using focused noble gas ions. By switching out the working gas of the HIM from helium to neon, it was possible to delicately remove the tip of the membranous sheath, while leaving the interior of the mouth cavity intact (Figure 5c). This reveals the interior mouth structure as well as the primary tooth morphology and DEGO shape and size (Figure 5b). The very precise milling ability of the neon beam was effectively demonstrated by cutting the exterior of the nematode with a final dose of 0.3鈥卬C/渭m3 (Figure 5d). This proved intense enough to cut through the outer skin of the worm without damaging any of the surrounding tissue. For deeper cuts (such as the one shown in Figure 5c), the final cutting dose was increased to 30鈥卬C/渭m3 to penetrate the entire depth of the worm and efficiently mill through some of the tougher, more filamentous portions of the sample such as the mechanosensory fibers around the nematode head.Figure 5HIM imaging of Pristionchus pacificus.(a) Native imaging of the nematode revealed the interior mouth cavity and tooth structures were obscured by a sheath-like structure. (b) neon milling of the outer sheath in the HIM revealed the primary tooth and DEGO structure of the nematode with minimal thermal damage to the cutting surface. (c) The removal of the outer sheath was performed in a very controlled manner with a final dose of 30鈥卬C/渭m3. (d) The delicate nature of the neon milling was demonstrated by the patterning of a small horizontal line using a dose of 0.3鈥卬C/渭m3. Despite being strong enough to penetrate the outer cuticle of the nematode, minimal ablation and thermal damage is visible on the surrounding area. Scale Bars: (a鈥揷) 5鈥呂糾 (d) 1鈥呂糾.Full size imageDiscussionOur results demonstrate both novel and exciting applications for helium ion microscopy in visualizing the surface ultrastructure of biological specimens at an unparalleled level of resolution and contrast. Specifically, we show that the common charging artifacts with the FE-SEM can be greatly reduced using the HIM approach. Moreover, the low sputtering rate of the helium ions beam for organic materials enables the repeated imaging of small and delicate surface features with no discernable beam damage. Also, we show that the heavy metal coating as generally required for SEM introduces clearly resolvable structural artifacts and HIM is a superior method in clearly revealing surface features at high magnification. Finally, we couple a neon ion beam with the HIM setup allowing us to mill away surface membranes and provide us with unprecedented access to sub-surface structures. The viability of this approach centers on the sputter rates of neon being four times lower than that of gallium19. As such, the neon ion beam is ideally suited for the precision milling of very small and delicate biological structures. In addition, it causes far less discernable sample damage, or metal ion deposition, as is sometimes the case when using liquid metal ion sources such as gallium37,38.The resolution attained using HIM imaging is far greater than that obtained from a traditional FE-SEM approach. This higher resolution necessitates the development of new protocols for sample preparation, particularly to mitigate the possibility of fixation and drying artifacts. Cryo-immobilization offers a proven and reliable alternative for the current fixation and dehydration approaches. We suggest that combining this cryo-based sample preparation paradigm with HIM will allow routine imaging with little or no artifacts.In conclusion we believe that this novel imaging method enabling the observation of completely unmodified structures on the nanometer scale will revolutionize our ability to interrogate both surface and sub-surface structures and provide deep scientific insights into the nanoscale architecture of biological specimens and soft materials.MethodsSamples were grown/cultured and subsequently fixed and critical point/freeze dried using the following methods. After the drying stage, the samples were carefully removed and adhered to double-sided carbon tabs on aluminum stubs and stored in a desiccator. For SEM imaging, the Arabidopsis thaliana, HeLa cells and Pristionchus pacificus samples were imaged on a Zeiss Sigma VP FE-SEM (Carl Zeiss, Cambridge, UK) and the Acidovorax sp. samples were imaged on a Zeiss Crossbeam 1540XB (Carl Zeiss, Oberkochen, Germany) using the parameters mentioned above. All samples were subsequently imaged on a Zeiss Orion PLUS HIM (Carl Zeiss, Peabody, MA).Arabidopsis thalianaGrowthWild type Arabidopsis were grown in soil to stage 6. Plants were trimmed by carefully pinching off regions of interest using two pairs of #5 forceps and the subsequent pieces were placed into ice-cold 100% EM grade ethanol for fixation.Critical point dryingThe ethanol fixed plant pieces were placed into a Teflon carrier for separation and into an automated critical point drier (Leica EM CPD300, Leica Vienna) which was set to perform 25 exchange cycles of CO2 at medium speed and 20% stirring. All additional fill, heating and venting steps were performed at medium speed as well. After drying, the samples were carefully removed and adhered to double-sided carbon tabs on aluminum stubs and stored in a desiccator.HeLa cellsCoverslip preparationCleaned 22 脳 22鈥卪m no. 1.5 coverslips were coated with a 1脳 solution of poly-L lysine for 15 minutes and air-dried at room temperature. Coated coverslips were then sterilized by UV light (NuAire cell culture cabinet) for 15 minutes on each side and stored until use.Cell cultureHeLa cells were cultured in DMEM (Sigma-Aldrich) supplemented with 10% fetal bovine serum, 1.0% l-glutamine with 0.018% NaHCO3 and penicillin/streptomycin in 5% CO2 and 95% air in a Thermo Scientific Forma Series II Water Jacketed CO2 cell culture incubator at 37掳C. Cells were allowed to grow for at least 36 hours from the previous passage until reaching 60鈥?0% confluency before passage again. Cells were washed twice with 2鈥?鈥卪ls of room temperature 1脳 DPBS and the trypsinized with 1鈥?鈥卪ls of 0.05% Trypsin-EDTA (Life Technologies) for 5鈥?0 minutes at 37掳C. Trypsin was neutralized with 2鈥?鈥卪l of 37掳C complete media and collected in a 15鈥卪l conical vial. 80,000鈥?20,000 cells (per well) were plated in 6-well plates containing 3鈥卪ls of complete media and a single poly-L lysine coated coverslip. Cells were allowed to grow for 36鈥?8 hours to ensure that the cells enter the exponential growth phase prior to fixation. Shorter periods of growth or over confluency yielded a much lower percentage of mitotic cells upon fixation.Cell fixationPlated cells were gently rinsed with 2鈥卪ls of 37掳C DPBS and aspirated off prior to fixation. 3鈥?鈥卪ls of freshly prepared 37掳C fixation solution containing 4% paraformaldehyde and 2% glutaraldehyde in DPBS was applied for 30 minutes at 37掳C and swapped with fresh 37掳C fixative to continue fixing for 1.5 hours at 37掳C. Once the cells were fixed they washed briefly in DI water and were either critically point dried or were stored at 4掳C in 1% paraformaldehyde and 2% glutaraldehyde in DPBS.Critical point dryingFixed coverslips were placed into an automated critical point drier (Leica EM CPD300, Leica Vienna) which was set to perform 25 exchange cycles of CO2 at medium speed and 20% stirring. All additional fill, heating and venting steps were performed at medium speed as well. After drying, the samples were carefully removed and adhered to double-sided carbon tabs on aluminum stubs and stored in a desiccator.Iron-oxidizing bacteria (BoFeN1)Cell cultureCultures of the nitrate-reducing Acidovorax sp. strain BoFeN1 were grown under anoxic conditions as described previously33. In brief, cells were grown in anoxic freshwater medium with initial concentrations of 10鈥卪M Fe2+ and 10鈥卪M nitrate and 5鈥卪M acetate. Samples of the cell suspension were taken with syringes after 5 to 6 days of incubation when Fe(II) is completely oxidized39.Critical point drying1鈥卪L of a centrifuged aliquot of the cell suspension were treated with 2.5% glutaraldehyde at 4掳C for 1 hour. The samples were rinsed twice with deionized water and deposited onto 10鈥卪m glass cover slips that were previously coated with a 8鈥卬m Pt-layer and poly-l-lysine. After 20 minutes to ensure binding of cell-mineral aggregates to the poly-l-lysine layer, the samples were rinsed with de-ionized water und subsequently dehydrated in a series of ethanol dilutions (30%, 70%, 95% and 3脳 100% dried on molecular sieve) with an equilibration step of 10 minutes each. The samples were then placed in a critical point dryer (Polaron E3000), wherein the ethanol was replaced by liquid CO2 at 1掳C. After flushing of 3 脳 200鈥単 CO2 with 20 minute equilibration periods after each step the temperature was gradually increased to 38掳C while the pressure was monitored and adjusted to reach and remain at 84 bars. This ensured bypassing the critical point when the pressure was released from 84 bars to atmospheric pressure. Half of the samples were then sputter-coated with a 4鈥卬m platinum layer using a BALZERS-UNION MED 010 (BAL-TEC, Liechtenstein) sputter coater. After reaching a vacuum of 8*10鈭?鈥卪bar, the sputtering process at was started in 2*10鈭?鈥卪bar of Ar.Rapid freezing followed by freeze-dryingTo be able to compare samples treated after the standard sample preparation protocol of CPD with a more natural state of the cell-mineral aggregates, we decided to use a physical fixation (rapid-freezing) instead of chemical fixation, followed by freeze-drying under high vacuum. Since the cell-mineral aggregates of BoFeN1 are within the 渭m size ranges, high-pressure freezing was not required to avoid the formation of ice crystals, but plunge-freezing in liquid propane was sufficient. Therefore, droplets of the cell suspension were deposited onto formvar-coated 300 mesh TEM-grids. They were blotted with filter paper and immediately shot into liquid propane at liquid-nitrogen (LN2) temperature ( 鈭?96掳C). The grids were stored in LN2 until freeze-drying. Freeze-drying was done on the cooling stage of a BAL-TEC BA 500 high vacuum coater. The grids were placed on the cooling stage at 鈭?20掳C. Thermal conduction between the sample and the stage was ensured by a small droplet of liquid propane, which also prevented ice formation on the stage during sample transfer. The stage was gradually heated up to 鈭?2掳C, while maintaining the pressure in the recipient below 5*10鈭?鈥卪bar. The progress of freeze-drying was followed visually. Upon complete disappearance of the ice after approximately 35鈥?5 minutes, the stage was gradually heated up to +25掳C before the chamber was vented and the samples could be removed. Half of the samples were sputter-coated with a 4鈥卬m Pt layer as described previously.Predator nematode - pristionchus pacificusWorm culturePristionchus pacificus specimens (strain identification: rlh24) were raised on agar plates coated with E. coli (OP50)40. At the young adult stage, worms were rinsed 3脳 in saline buffer (M9) and transferred to an uncoated agar plate. Worms then remained off food for 5 hours, providing sufficient time for P. pacificus to consume residual E. coli adherent to their exterior cuticle. This process is critical to produce a clean imaging sample. The predators were then fixed by placing them into a solution of ice-cold 100% EM grade ethanol.Critical point dryingThe ethanol fixed worms were placed into a 30鈥卪m porous pot (Electron Microscopy Sciences (EMS) cat# 70187-20) and into an automated critical point drier (Leica EM CPD300, Leica Vienna) which was set to perform 25 exchange cycles of CO2 at medium speed and 20% stirring. All additional fill, heating and venting steps were performed at medium speed as well. After drying, the samples were carefully removed and adhered to double-sided carbon tabs on aluminum stubs and stored in a desiccator. ReferencesBozzola, J. J. Russell, L. D. Electron microscopy: principles and techniques for biologists. 2nd edn, (Jones and Bartlett, 1999).Denk, W. Horstmann, H. Serial Block-Face Scanning Electron Microscopy to Reconstruct Three-Dimensional Tissue Nanostructure. PLoS Biol 2, e329, 10.1371/journal.pbio.0020329 (2004).CAS聽 Article聽 PubMed聽 PubMed Central聽 Google Scholar聽 Stokes, D. J., Morrissey, F. Lich, B. H. A New Approach to Studying Biological and Soft Materials Using Focused Ion Beam Scanning Electron Microscopy (FIB SEM). J. Phys.: Conf. Ser. 26, 50 (2006).ADS聽 Google Scholar聽 Crang, F. E. Klomparens, K. L. Artifacts in biological electron microscopy. (Plenum Press, New York London, 1988).Pathan, A. K., Bond, J. Gaskin, R. E. Sample preparation for scanning electron microscopy of plant surfaces-Horses for courses. Micron 39, 1049鈥?061, 10.1016/j.micron.2008.05.006 (2008).CAS聽 Article聽 PubMed聽 Google Scholar聽 Timp, W. Matsudaira, P. in Biophysical Tools for Biologists, Vol 2: In Vivo Techniques Vol. 89 Methods in Cell Biology (eds Correia J. J., Detrich H. W.) 391鈥?07 (Elsevier Academic Press Inc, 2008).Book聽 Google Scholar聽 Reimer, L. Image formation in low-voltage scanning electron microscopy. (SPIE Optical Engineering Press, 1993).Bell, D. C. Erdman, N. Low Voltage Electron Microscopy: Principles and Applications. First edn, Vol. 1 (John Wiley Sons Ltd., 2013). Google Scholar聽 Joy, D. C. Joy, C. S. Low voltage scanning electron microscopy. Micron 27, 247鈥?63 (1996).Article聽 Google Scholar聽 Pawley, J. Schatten, H. Biological Low-Voltage Scanning Electron Microscopy. First edn, (Springer, 2008).Cazaux, J. About the Mechanisms of Charging in EPMA, SEM and ESEM with Their Time Evolution. Microsc Microanal 10, 670鈥?84, 10.1017/S1431927604040619 (2004).CAS聽 ADS聽 Article聽 PubMed聽 Google Scholar聽 Stabentheiner, E., Zankel, A. P枚lt, P. Environmental scanning electron microscopy (ESEM)鈥揳 versatile tool in studying plants. Protoplasma 246, 89鈥?9, 10.1007/s00709-010-0155-3 (2010).Article聽 PubMed聽 Google Scholar聽 Bergmans, L., Moisiadis, P., Van Meerbeek, B., Quirynen, M. Lambrechts, P. Microscopic observation of bacteria: review highlighting the use of environmental SEM. Int Endod J 38, 775鈥?88, 10.1111/j.1365-2591.2005.00999.x (2005).CAS聽 Article聽 PubMed聽 Google Scholar聽 Stokes, D. J., Mugnier, J. Y. Clarke, C. J. Static and dynamic experiments in cryo-electron microscopy: comparative observations using high-vacuum, low-voltage and low-vacuum SEM. J Microsc 213, 198鈥?04, 10.1111/j.1365-2818.2004.01282.x (2004).CAS聽 MathSciNet聽 Article聽 PubMed聽 Google Scholar聽 Echlin, P. Low-temperature microscopy and analysis. (Plenum Press, 1992).Yu, Z., Chen, H., Tong, Y. Wu, P. in Rice Protocols Vol. 956 Methods in Molecular Biology (ed Yinong Yang) Ch. 17, 243鈥?48 (Humana Press, 2013).Book聽 Google Scholar聽 Ward, B. W., Notte, J. A. Economou, N. P. 6 edn 2871鈥?874 (AVS).M眉ller, E. W. Bahadur, K. Field Ionization of Gases at a Metal Surface and the Resolution of the Field Ion Microscope. Phys Rev 102, 624鈥?31 (1956).ADS聽 Article聽 Google Scholar聽 Hill, R., Notte, J. A. Scipioni, L. in Advances in Imaging and Electron Physics Vol. Volume 170 (ed Hawkes Peter W.) 65鈥?48 (Elsevier, 2012). Google Scholar聽 Bell, D. Contrast Performance: Low Voltage Electrons vs. Helium Ions. Microsc Microanal 17, 660鈥?61, 10.1017/S143192761100417X (2011).ADS聽 Article聽 Google Scholar聽 Bell, D. C. Contrast Mechanisms and Image Formation in Helium Ion Microscopy. Microsc Microanal 15, 147鈥?53, 10.1017/S1431927609090138 (2009).CAS聽 ADS聽 Article聽 PubMed聽 Google Scholar聽 Ramachandra, R., Griffin, B. Joy, D. A model of secondary electron imaging in the helium ion scanning microscope. Ultramicroscopy 109, 748鈥?57, 10.1016/j.ultramic.2009.01.013 (2009).CAS聽 Article聽 PubMed聽 Google Scholar聽 Joy, D. C. Griffin, B. J. Is Microanalysis Possible in the Helium Ion Microscope? Microsc Microanal 17, 643鈥?49, 10.1017/s1431927611000596 (2011).CAS聽 ADS聽 Article聽 PubMed聽 Google Scholar聽 Postek, M. T., Vladar, A. E. Bin, M. Recent progress in understanding the imaging and metrology using the helium ion microscope. Proc SPIE-Int Soc Opt Eng 7378, 737808 (737810 pp.)鈥?37808 (737810 pp.), 10.1117/12.824533 (2009).Article聽 Google Scholar聽 Gerlach, D. et al. Nanofibers in a hyaluronan-based pericellular matrix. Matrix Biol 29, 664鈥?67, 10.1016/j.matbio.2010.08.006 (2010).CAS聽 Article聽 PubMed聽 Google Scholar聽 Bazou, D., Behan, G., Reid, C., Boland, J. J. Zhang, H. Z. Imaging of human colon cancer cells using He-Ion scanning microscopy. J Microsc 242, 290鈥?94, 10.1111/j.1365-2818.2010.03467.x (2011).CAS聽 Article聽 PubMed聽 Google Scholar聽 Vanden Berg-Foels, W. S., Scipioni, L., Huynh, C. Wen, X. Helium ion microscopy for high-resolution visualization of the articular cartilage collagen network. J Microsc 246, 168鈥?76, 10.1111/j.1365-2818.2012.03606.x (2012).CAS聽 Article聽 PubMed聽 Google Scholar聽 Boden, S. A., Asadollahbaik, A., Rutt, H. N. Bagnall, D. M. Helium ion microscopy of Lepidoptera scales. Scanning 34, 107鈥?20, 10.1002/sca.20267 (2012).Article聽 PubMed聽 Google Scholar聽 Rice, W. L. et al. High resolution helium ion scanning microscopy of the rat kidney. PloS one 8, 10.1371/journal.pone.0057051 (2013).Boseman, A., Nowlin, K., Ashraf, S., Yang, J. Lajeunesse, D. Ultrastructural analysis of wild type and mutant Drosophila melanogaster using helium ion microscopy. Micron 51, 26鈥?5, 10.1016/j.micron.2013.06.005 (2013).CAS聽 Article聽 PubMed聽 Google Scholar聽 Chen, X. et al. Whole-Cell Imaging at Nanometer Resolutions Using Fast and Slow Focused Helium Ions. Biophys J 101, 1788鈥?793, 10.1016/j.bpj.2011.08.028 (2011).CAS聽 Article聽 PubMed聽 PubMed Central聽 Google Scholar聽 Klueglein, N. Kappler, A. Abiotic oxidation of Fe(II) by reactive nitrogen species in cultures of the nitrate-reducing Fe(II) oxidizer Acidovorax sp BoFeN1 - questioning the existence of enzymatic Fe(II) oxidation. Geobiology 11, 180鈥?90, 10.1111/gbi.12019 (2013).CAS聽 Article聽 PubMed聽 Google Scholar聽 Kappler, A., Schink, B. Newman, D. K. Fe(III) mineral formation and cell encrustation by the nitrate-dependent Fe(II)-oxidizer strain BoFeN1. Geobiology 3, 235鈥?45, 10.1111/j.1472-4669.2006.00056.x (2005).CAS聽 Article聽 Google Scholar聽 Montesinos, E., Esteve, I. Guerrero, R. Comparison between direct methods for determination of microbial cell-volume - Electron-Microscopy and Electronic Particle Sizing. Appl Environ Microbiol 45, 1651鈥?658 (1983).CAS聽 PubMed聽 PubMed Central聽 Google Scholar聽 Bumbarger, D. J., Riebesell, M., Rodelsperger, C. Sommer, R. J. System-wide Rewiring Underlies Behavioral Differences in Predatory and Bacterial-Feeding Nematodes. Cell 152, 109鈥?19, 10.1016/j.cell.2012.12.013 (2013).CAS聽 Article聽 PubMed聽 Google Scholar聽 Giblin-Davis, R. M. et al. Stomatal ultrastructure, molecular phylogeny and description of Parasitodiplogaster laevigata n. sp (Nematoda: Diplogastridae), a parasite of fig wasps. J Nematol 38, 137鈥?49 (2006).CAS聽 PubMed聽 PubMed Central聽 Google Scholar聽 Tondare, V. N. Quest for high brightness, monochromatic noble gas ion sources. J Vac Sci Technol A 23, 1498鈥?508, 10.1116/1.2101792 (2005).CAS聽 ADS聽 Article聽 Google Scholar聽 Drobne, D., Milani, M., Zrimec, A., Leser, V. Berden Zrimec, M. Electron and ion imaging of gland cells using the FIB/SEM system. J Microsc 219, 29鈥?5, 10.1111/j.1365-2818.2005.01490.x (2005).CAS聽 MathSciNet聽 Article聽 PubMed聽 Google Scholar聽 Miot, J. et al. Iron biomineralization by neutrophilic nitrate-reducing iron-oxidizing bacteria. Geochim Cosmochim Ac 73, A884鈥揂884 (2009).Article聽 Google Scholar聽 Sommer, R. J. Pristionchus pacificus., WormBook, ed. The C. elegans Research Community, WormBook, 10.1895/wormbook.1.7.1 (2006), http://www.wormbook.org.Download referencesAcknowledgementsWe gratefully acknowledge financial support from the Waitt Advanced Biophotonics Center endowment (J.M.K., M.S.J. and J.A.J.F.), NCI P30 Cancer Center Support Grant CA014195-39 (Y.J.S. and J.A.J.F.), NINDS P30 Neuroscience Center Core Grant NS072031-01A1 (M.S.J. and J.A.J.F.) and DFG Emmy Noether grant OB 362/1-1 (F.Z. and M.O.). We would also like to thank the Ion Microscopy Innovation Center at Carl Zeiss Microscopy (Peabody, MA) for providing access to an Orion PLUS helium ion microscope, Carl Procko from the Chory lab at the Salk Institute for providing wild-type Arabidopsis Thaliana for HIM imaging experiments and Kat Kearny for critical reading of the manuscript and for helpful suggestions regarding organization and formatting.Author informationAffiliationsWaitt Advanced Biophotonics Center, Salk Institute for Biological Studies, 10010 North Torrey Pines Road, La Jolla, CA, 92037, USAMatthew S. Joens,聽James M. Kasuboski,聽Yury J. Sigal聽 聽James A. J. FitzpatrickIon Microscopy Innovation Center, Carl Zeiss Microscopy LLC, One Corporation Way, Peabody, MA, 01960, USAChuong Huynh,聽David Ferranti,聽Lewis A. Stern聽 聽Bernhard GoetzeCenter for Applied Geosciences, University T眉bingen, Hoelderlinstr. 12, 72074, Tuebingen, GermanyFabian Zeitvogel聽 聽Martin ObstNMI Natural and Medical Sciences Institute, Markwiesenstr. 55, 72770, Reutlingen, GermanyClaus J. BurkhardtMolecular Neurobiology Laboratory, Salk Institute for Biological Studies, 10010 North Torrey Pines Road, La Jolla, CA, 92037, USAKevin P. Curran聽 聽Sreekanth H. ChalasaniAuthorsMatthew S. JoensView author publicationsYou can also search for this author in PubMed聽Google ScholarChuong HuynhView author publicationsYou can also search for this author in PubMed聽Google ScholarJames M. KasuboskiView author publicationsYou can also search for this author in PubMed聽Google ScholarDavid FerrantiView author publicationsYou can also search for this author in PubMed聽Google ScholarYury J. SigalView author publicationsYou can also search for this author in PubMed聽Google ScholarFabian ZeitvogelView author publicationsYou can also search for this author in PubMed聽Google ScholarMartin ObstView author publicationsYou can also search for this author in PubMed聽Google ScholarClaus J. BurkhardtView author publicationsYou can also search for this author in PubMed聽Google ScholarKevin P. CurranView author publicationsYou can also search for this author in PubMed聽Google ScholarSreekanth H. ChalasaniView author publicationsYou can also search for this author in PubMed聽Google ScholarLewis A. SternView author publicationsYou can also search for this author in PubMed聽Google ScholarBernhard GoetzeView author publicationsYou can also search for this author in PubMed聽Google ScholarJames A. J. FitzpatrickView author publicationsYou can also search for this author in PubMed聽Google ScholarContributionsM.S.J., J.M.K. and Y.J.S. were responsible for the preparation of the plant and cell culture samples and M.S.J. and C.H. undertook the plant, nematode and cell HIM imaging experiments. C.H. and D.F. undertook the neon cutting of nematode experiments. F.Z., M.O. and C.B. were responsible for the preparation of the bacterial samples and the bacterial HIM imaging. Worm samples were prepared by K.C. and S.H.C. Study was conceived by B.G. and J.A.J.F., M.S.J. and J.A.J.F. prepared the figures and wrote the manuscript with contributions from M.O., C.B., L.A.S. and B.G.Ethics declarations Competing interests The author(s) declare that Chuong Huynh, David Ferranti, Lewis Stern and Bernhard Goetze are employed by the manufacturer of the commercial Orion PLUS Helium Ion Microscope (Carl Zeiss Microscopy, LLC). No other competing financial interests apply. Electronic supplementary material Supplementary InformationSupplementary InformationRights and permissions This work is licensed under a Creative Commons Attribution-NonCommercial-NoDerivs 3.0 Unported License. To view a copy of this license, visit http://creativecommons.org/licenses/by-nc-nd/3.0/ Reprints and PermissionsAbout this articleCite this articleJoens, M., Huynh, C., Kasuboski, J. et al. Helium Ion Microscopy (HIM) for the imaging of biological samples at sub-nanometer resolution. Sci Rep 3, 3514 (2013). https://doi.org/10.1038/srep03514Download citationReceived: 02 October 2013Accepted: 26 November 2013Published: 17 December 2013DOI: https://doi.org/10.1038/srep03514 Heejin Lim, Sun Young Lee, Yereum Park, Hyeonggyu Jin, Daeha Seo, Yun Hee Jang Dae Won Moon Nature Methods (2021) Malte Gro脽mann, Maximilian Black, Joris Jaruschewski, Alwin Klick, Till Lei脽ner, Jacek Fiutowski, Horst-G眉nter Rubahn Michael Bauer Plasmonics (2021) Channarong Sartsanga, Rinyaporn Phengchat, Kiichi Fukui, Toshiyuki Wako Nobuko Ohmido Chromosome Research (2021) CommentsBy submitting a comment you agree to abide by our Terms and Community Guidelines. If you find something abusive or that does not comply with our terms or guidelines please flag it as inappropriate. Sign up for the Nature Briefing newsletter 鈥?what matters in science, free to your inbox daily.
